Backing Material Closed cell PVC / nitrile foam
Adhesive Type Acrylic
Density (ASTM D-1667) 64 - 112 kg/m3
Compression Deflection (ASTM D1050-85) 14 - 35 kPa
Compression Set 25% loss from original height
Water Absorption 10% by volume
90° Peel Adhesion 411 N/m
Elongation (ASTM D412-83) 100%
Thermal Conductivity (ASTM C518) 0.031 kcal/(m.h.°C)
Service Temperature -29°C to +104°C
Application Temperature +4°C to +52°C
Colour Available Black
THICKNESSES: 3.0mm / 6.0mm / 9.0mm
STORAGE: Cartons should be sealed and stored away from direct sunlight
at temperatures between 15°C to 30°C

- Good resistance to fungi, weather and oxidation
- Completely seals out air, moisture and light when compressed at least 30%
- Dimensionally stable; will not ooze, drip or run
- Conformable to rough surfaces to ensure a positive seal
- Remains flexible at a wide range of operating temperatures
- Good resistance to most chemicals
- RoHS compliant
