Backing Material Low density closed cell PVC foam
Adhesive Type Acrylic
Density 112 kg/m3
Tensile Strength (ASTM D412) 173 kPa
Elongation (ASTM D412) 150%
Hardness – Shore 00 (ASTM D2240) 14
Compression Deflection @25% (ASTM D1667) 6 kPa
Compression Set @25% (ASTM D1667) 4% loss from original height
Water Absorption 1.1%
Thermal Conductivity (K factor) (ASTM C518) 0.039 W/m K
Service Temperature -40°C to +80°C
Application Temperature +10°C to +45°C
Colour Available Black
THICKNESSES: 3.2mm / 6.4mm / 9.5mm / 12.7mm / 19.0mm
STORAGE: Cartons should be sealed and stored away from direct sunlight
between temperatures of 15°C to 30°C

- Seals out smoke, air, moisture and light when compressed at least 30%
- Easy to compress and conformable but is still strong and resilient
- Excellent resistance to fungi, weather and oxidation
- Specifically formulated to meet automotive industry specification, GM 6086M-IA, Ford ESB M3G, Chrysler MSAY 511-A, B and C Self-extinguishing formulation, meets FMVSS 302A


  • Danco 77 Series Foam Tape Data Sheet
