Armstrong

Armstrong Metalworks C & S Planks

Metal Ceiling Systems

Armstrong Metalworks C & S Plank system allows for concealed monolithic visual in large open space or corridors. This ceiling system combines four widths of strips panels which are distinguished from it’s closed smooth appearance with distinct V-shaped grooves when installed. The C & S Planks are available in 100mm, 150mm, 200mm and 300mm widths, in plain or perforated finish to add acoustic performance, and in a variety of colour or Wood Effect finishes.

Documents

Suitable for: Ceilings, Metal, Commercial, Education, Office, Interior, Industrial, Retail, Warehouse, Hospitality, Feature Products, Mixed Use, Hall / Conference, Non-Structural, School, Specialty, Entrance / Lobby, Acoustic, Transport
Available widths: 100mm, 150mm, 200mm, 300mm
Material: Aluminium (thickness 0.60 – 0.90mm)
Suspension system material: Galvanised Steel
Surface finish: Powdercoated in RAL 9016 Satin White. Other colours including Wood Effects available upon request.
Edge detail: 3mm bevel
Acoustic performance: NRC up to 0.75 with Acoustical Fleece
Weight: 5.2kg/m2
Fire performance: Conforms with BCA Spec. C1.10 and tested to AS/NZS 3837:1998 – Group 1, ISO 5660 – Group 1–S

Specification

Benefits

Monolithic Linear visual with concealed suspension grid
Acoustical performance with microperforated panels
Fast and easy installation with minimal plenum clearance
Durable: washable, scratch and impact resistant
