• Monolithic appearance
  • Concealed suspension System
  • 100% downward accessibility with panel removal tool
  • Custom sizes, finishes and perforation options available, including “chilled beam compatible” designs
  • TOTAL ACOUSTICS™ Performance Options (NRC+CAC)
    • Excellent sound attenuation, improving room to room privacy
    • High sound absorption for reduced reverberation and quieter spaces
  • Sustainable Contribution
    • Global GreenTagCERT TM GreenRate™ Level A Certified for Green Star™
    • GreenTagCERT TM Gold Health Product Rating for WELL™ Building Standard™
Acoustic performance
  • NRC up to 0.75 with Acoustical Fleece
  • NRC up to 0.90 with Acoustical Infill
  • CAC up to 18dB with Acoustical Fleece
  • CAC up to 38dB with “B15” Mineral Acoustical Infill
  • CAC up to 40dB with “B19” Mineral Acoustical Infill.

Recommended Suspension System is a U-Profile Channels to be suspended on 5mm Rod and Suspension Clips at 1200mm centres. A Rails to be installed from U-Profile Channels by A Rail Hangers and located according to panel size and configuration. Refer to METALWORKS Clip-In Ceiling Installation Details for more information.
