Specification

Benefits
  • Semi-concealed grid for a monolithic effect.
  • Cost effective installation on standard 24mm Peakform grid.
  • Simple accessibility: Downward demountable with minimal plenum clearance.
  • Custom sizes, finishes and perforation options available, including “chilled beam compatible” designs.
  • High sound absorption for reduced reverberation and quieter spaces.
  • Sustainable Contribution
    • Global GreenTagCERT TM GreenRate™ Level A Certified for Green Star™
    • GreenTagCERT TM Gold Health Product Rating for WELL™ Building Standard™
Key features
  • Semi-concealed grid for a monolithic effect
  • Cost effective
  • Installs easily on standard 24mm Peakform Tee grid
  • Minimal plenum clearance
  • Simple accessibility
Acoustic performance
  • NRC up to 0.75 with Acoustical Fleece
  • Up to NRC 0.90 with Acoustical Infill
  • CAC up to 18dB with Acoustical Fleece
  • CAC up to 38dB with “B15” Mineral Acoustical Infill
  • CAC up to 40dB with “B19” Mineral Acoustical Infill.

Recommended Suspension System is Armstrong Peakform 24mm grid. Please refer to METALWORKS Vector Ceiling Installation Details for more information.

Click here for MasterSpec specification link
